Monochrome Segment LCD Display STN Blue LCD Screen
This high-contrast Monochrome Segment LCD Display STN Blue LCD Screen offering a 10-year lifespan and low power consumption.
Module No: JDA0801-25140A1
Technology: COB technology
Connector: PIN
Polarizer Type: Transmissive
Operating Temp: 0 to 50℃
Perfect for electronic scales and POS machines. Contact us for custom solutions and a 24-hour quote.
Send Inquiry
Product Description
|
Clear & Professional Monochrome Segment LCD Display STN Blue LCD Screen |
Our Monochrome Segment LCD Display STN Blue LCD Screen offers an excellent combination of simplicity, cost-effectiveness, and durability. Featuring a blue background with white display segments, this screen provides clear visual information, excellent contrast, and a professional appearance.
|
Key Features ▸ Clear STN Display: Blue background with white characters for easy reading. ▸ Customized Patterns: Supports numerical displays, icons, symbols, and indicators. ▸ Flexible Design: Customized LCD dimensions, viewing areas, and glass thickness. ▸ Low Power Consumption: Ideal for battery-powered electronic devices. |
Core Specifications Module No: JDA0801-25140A1 LCD Type: STN / Blue Technology: COB Voltage: 5.0V Connector: PIN View Angle: 12 o'clock |
Technical Parameters
|
Module Size 61(W)×41(H)×5.6(T)mm |
Display VA 60(W)×39(H)mm |
|
LCD Type STN / Blue |
Operating Voltage 5.0V |
|
View Angle 12 o'clock |
Connector PIN |
|
Drive Method 1/8 DUTY, 1/3 BIAS |
Polarizer Type Transmissive |
|
Operating Temp. 0 to 50℃ |
Storage Temp. -20 to 60℃ |
Applications
The Monochrome Segment LCD Display STN Blue LCD Screen is suitable for electronic products that require numerical information, functional icons, and operating status indicators. Its minimal power consumption makes it ideal for battery-powered devices, wearables, medical devices, and IoT sensors.
|
STN Blue Segment LCD Display used in POS terminals. |
Monochrome STN Blue LCD Screen applied in digital scales. |
Why Choose JINGDA Display?
JDA company is a professional segment LCD display manufacturer and supplier in Shenzhen, China. We have been focusing on the LCD display field for 10 years. Our LCD products have the advantage of high cost-effectiveness and can provide a good LCD solution for clients. This LCD display has a long lifespan of 10 years and is sold domestically and internationally.
We have passed ISO9001, ISO14001, and IATF-16949 system certifications. If you are looking for other segment display options, you can review our Segment LCD Display category. For high-contrast negative mode, we recommend the Segment LCD Display VA Negative LCD Mode. You can also explore our Character LCD Display and Graphic LCD Display ranges.
|
|
FAQ
| Can you provide samples before mass production? | Yes. Sample development and evaluation are available for customized LCD projects. Customers can provide drawings, technical specifications, or reference samples. |
| Can you provide an inspection report for the LCD modules? | Yes. Jingda Display can provide actual production inspection records according to the agreed quality requirements. |
| What is the MOQ of this segment LCD display? | For standard versions, the MOQ is flexible and low, often starting from 1 thousand pieces. For fully customized modules, the MOQ depends on the tooling and manufacturing setup. |
| What is the warranty period? | Our standard warranty is 12 months from shipment, covering manufacturing defects. Long-term reliability data and aging test results are available on request. |
