7 inch TFT Embedded Industrial Control All-in-One Device

High-Visibility Display 7 inch TFT embedded industrial control all-in-one device, it supports multiple operating systems such as Linux, Android, or Windows IoT, making it versatile for various industrial scenarios.
Resolution: 1024*600
Brightness: 1000cd/㎡
Input interface: LVDS
Touch Type: Projected CTP
Backlight Lifespan: 50000H

Send Inquiry

Product Description

Product Parameters

Module Screen Parameters
Display Dimension	7 inch(BOE)
Display Ratio	16:9
Resolution	1024*600
Brightness	1000cd/㎡
Contrast Ratio	1000:1
Signal Input Interface	LVDS
Backlight Lifespan	50000H
Touchscreen Parameters
Touch Type	Projected CTP
Touch Screen Surface	Transparent
Surface Hardness	≥6H
Touch Technology	Finger touch/capacitive pen touch

Product Introductions

JDA’s 7 inch TFT embedded industrial control all-in-one device is a compact, high-performance integrated solution designed for industrial automation, intelligent equipment, and human-machine interface (HMI) applications. Featuring a 7-inch TFT LCD with a projected touchscreen, this all-in-one unit combines a display, processor, input/output interfaces, and optional connectivity modules into a single, durable enclosure. The single-point operation is Windows XP, Linux and multi-point operation is Windows7/8/10, Android. This all-in-one solution enhances operational efficiency, reduces downtime, and future-proofs industrial systems with its blend of compactness, durability, and advanced connectivity.

Applications

At present, the application fields of industrial control device have become very extensive. Including industrial automation, or industries such as medical care and transportation, industrial control device have been widely used.
